Build Assets Pipeline (Or: How I Turned a Simple Blog Into an Image Processing Factory)

The goal (four non-negotiable constraints)

Every image on this blog has to satisfy four constraints. Not "nice to have." Non-negotiable. Like my morning coffee.

1. Correct size for the viewport. No 2000px hero shipped to a phone.
2. Modern format where supported. WebP for browsers that accept it, raster fallback for the rest.
3. Zero cumulative layout shift. Width and height reserved BEFORE the image downloads.
4. Lazy on-reveal. Off-screen images do not block the main thread.

The pipeline that delivers that is entirely build-time. There is NO image CDN, no runtime resize, no magic. This post walks through each layer.

The input: a plain markdown image (looks boring, does magic)

The markdown source looks like a normal image:

![A keyboard on a wooden desk](../assets/images/keyboard.jpg)

What makes it responsive is NOT a special syntax. It's the build pipeline that sees the local path and does work behind the scenes. Magic? No. Engineering.

Optionally the author can provide a title meta string to override the default behavior:

![Hero](../assets/images/hero.jpg 'Hero | srcset=../img/320.jpg 320w, ../img/640.jpg 640w | priority=high')

Segments separated by | let you specify custom srcset, sizes, loading, and priority. For most images I omit all of that and let the pipeline fill in the defaults. Because defaults should be smart.

Stage 1: variants and the image manifest (sharp knives, hot takes)

Before the CMS runs, an image pipeline step generates responsive variants of every image under src/assets/images/:

• image.jpg → image-320.jpg, image-640.jpg, image-960.jpg, image-1280.jpg, NEVER upscaled;
• a WebP base (image.webp) and matching WebP variants at each size.

The output of that step is a manifest file (src/assets/images-manifest.json) with entries like:

{
  "/assets/images/keyboard.jpg": {
    "width": 1920,
    "height": 1280,
    "variants": [
      { "src": "/assets/images/keyboard-320.jpg", "width": 320 },
      { "src": "/assets/images/keyboard-640.jpg", "width": 640 }
    ]
  }
}

Sharp does the resizing. The manifest is the contract between the image step and the markdown renderer. Contracts are good. Trust me, I've been divorced.

Stage 2: the markdown renderer rewrites <img> into <picture> (the fun part)

When the renderer encounters an image with a local path, it looks up the manifest, computes srcset for WebP and raster sources, and emits a <picture> element:

<picture>
  <source type="image/webp" data-srcset="/assets/images/keyboard-320.webp 320w, ..." />
  <source type="image/jpeg" data-srcset="/assets/images/keyboard-320.jpg 320w, ..." />
  <img src="/assets/images/keyboard.jpg" alt="A keyboard on a wooden desk"
       width="1920" height="1280" loading="lazy" decoding="async" />
  <noscript>
    <img src="/assets/images/keyboard-640.jpg" alt="A keyboard on a wooden desk" />
  </noscript>
</picture>

Two details worth calling out because they matter:

Width and height come from the manifest. The browser reserves the correct aspect-ratio box BEFORE the pixels arrive, so there is ZERO layout shift when the image loads. This is the single most impactful CLS fix on any image-heavy page. If you're not doing this, you're doing it wrong.

data-srcset instead of srcset by default. The real srcset is swapped in by a tiny script when the image enters the viewport, which is how the "lazy on-reveal" policy is enforced. The <noscript> fallback covers users who disable JavaScript. Because not everyone lives in a perfect world.

Stage 3: the tiny observer that swaps data-srcset to srcset (12 lines, no framework)

The runtime piece is small. Embarrassingly small:

const io = new IntersectionObserver(
  (entries) => {
    for (const entry of entries) {
      if (!entry.isIntersecting) continue;
      const source = entry.target;
      if (source.dataset.srcset) {
        source.srcset = source.dataset.srcset;
        source.removeAttribute('data-srcset');
      }
      io.unobserve(source);
    }
  },
  { rootMargin: '200px' }
);

document.querySelectorAll('source[data-srcset]').forEach((s) => io.observe(s));

That's the ENTIRE lazy-load layer. Everything else is declarative markup the browser understands natively. No library. No framework. No bullshit.

Why not loading="lazy" alone? (the nuance part)

Native loading="lazy" is a good default and I use it on <img> elements. But it does NOT cover <source> elements inside <picture>. The IntersectionObserver swap handles the source selection path, which is where the large WebP variants are chosen.

On a page with a dozen images below the fold, the difference is measurable in bytes saved on initial load. Measurable matters.

What I did NOT do (because engineering is about saying no)

• No runtime image CDN. Every variant is on disk, served by GitHub Pages, cached at the edge.
• No AVIF yet. AVIF support is excellent, but WebP still beats it on encode time for the gains at the sizes this blog uses. I will reconsider when AVIF encoders catch up. Not today.
• No third-party "lazyload.js". Twelve lines of IntersectionObserver replaces it. Twelve. Lines.

The takeaway

Responsive images do NOT need a service. A build step that generates variants, a manifest the renderer reads, and a markdown pass that emits <picture> are enough. The result is small pages, correct sizes, known dimensions, and lazy behavior that respects the user.

No CDN. No runtime. No excuses.
