The goal
Every image on this blog has to satisfy four non-negotiable constraints:
- Correct size for the viewport. No 2000px hero shipped to a phone.
- Modern format where supported. WebP for browsers that accept it, raster fallback for the rest.
- Zero cumulative layout shift. Width and height reserved before the image downloads.
- Lazy on-reveal. Off-screen images do not block the main thread.
The pipeline that delivers that is entirely build-time. There is no image CDN, no runtime resize, no magic. This post walks through each layer.
The input: a plain markdown image
The markdown source looks like a normal image:
What makes it responsive is not a special syntax. It is the build pipeline that sees the local path and does work behind the scenes.
Optionally the author can provide a title meta string to override the default behavior:
 100vw, 640px | priority=high | loading=eager')
Segments separated by | let you specify custom srcset, sizes,
loading, and priority. For most images I omit all of that and let the pipeline
fill in the defaults.
Stage 1: variants and the image manifest
Before the CMS runs, an image pipeline step generates responsive variants of every image under
src/assets/images/:
-
image.jpg→image-320.jpg,image-640.jpg,image-960.jpg,image-1280.jpg, never upscaled; - a WebP base (
image.webp) and matching WebP variants at each size.
The output of that step is a manifest file (src/assets/images-manifest.json) with entries
like:
{
"/assets/images/keyboard.jpg": {
"width": 1920,
"height": 1280,
"variants": [
{ "src": "/assets/images/keyboard-320.jpg", "width": 320 },
{ "src": "/assets/images/keyboard-640.jpg", "width": 640 },
{ "src": "/assets/images/keyboard-960.jpg", "width": 960 },
{ "src": "/assets/images/keyboard-1280.jpg", "width": 1280 }
],
"webp": [{ "src": "/assets/images/keyboard-320.webp", "width": 320 }]
}
}Sharp does the resizing. The manifest is the contract between the image step and the markdown renderer.
Stage 2: the markdown renderer rewrites <img> into <picture>
When the renderer encounters an image with a local path, it looks up the manifest, computes
srcset for WebP and raster sources, and emits a <picture> element:
<picture>
<source
type="image/webp"
data-srcset="/assets/images/keyboard-320.webp 320w,
/assets/images/keyboard-640.webp 640w,
/assets/images/keyboard-960.webp 960w,
/assets/images/keyboard-1280.webp 1280w"
sizes="(max-width: 640px) 100vw, 640px"
/>
<source
type="image/jpeg"
data-srcset="/assets/images/keyboard-320.jpg 320w, ..."
sizes="(max-width: 640px) 100vw, 640px"
/>
<img
src="/assets/images/keyboard.jpg"
alt="A keyboard on a wooden desk"
width="1920"
height="1280"
loading="lazy"
decoding="async"
/>
<noscript>
<img src="/assets/images/keyboard-640.jpg" alt="A keyboard on a wooden desk" />
</noscript>
</picture>Two details worth calling out.
Width and height come from the manifest. The browser reserves the correct aspect-ratio box before the pixels arrive, so there is no layout shift when the image loads. This is the single most impactful CLS fix on any image-heavy page.
data-srcset instead of srcset by default. The real
srcset is swapped in by a tiny script when the image enters the viewport, which is how the
"lazy on-reveal" policy is enforced. The <noscript> fallback covers users who disable
JavaScript.
For LCP-critical images (covers, above-the-fold hero), the author sets priority=high or
loading=eager, and the renderer inlines real srcset attributes instead of
data-srcset. No waiting, no flash.
Stage 3: the tiny observer that swaps data-srcset to srcset
The runtime piece is small:
const io = new IntersectionObserver(
(entries) => {
for (const entry of entries) {
if (!entry.isIntersecting) continue;
const source = entry.target;
if (source.dataset.srcset) {
source.srcset = source.dataset.srcset;
source.removeAttribute('data-srcset');
}
io.unobserve(source);
}
},
{ rootMargin: '200px' }
);
document.querySelectorAll('source[data-srcset]').forEach((s) => io.observe(s));That is the entire lazy-load layer. Everything else is declarative markup the browser understands natively.
Why not loading="lazy" alone?
Native loading="lazy" is a good default and I use it on <img> elements.
But it does not cover <source> elements inside <picture>. The
IntersectionObserver swap handles the source selection path, which is where the large WebP variants are
chosen.
On a page with a dozen images below the fold, the difference is measurable in bytes saved on initial load.
What I did not do
- No runtime image CDN. Every variant is on disk, served by GitHub Pages, cached at the edge.
- No AVIF yet. AVIF support is excellent, but WebP still beats it on encode time for the gains at the sizes this blog uses. I will reconsider when AVIF encoders catch up on the CPU side.
- No third-party "lazyload.js". Twelve lines of IntersectionObserver replaces it.
The takeaway
Responsive images do not need a service. A build step that generates variants, a manifest the renderer
reads, and a markdown pass that emits <picture> are enough. The result is small pages,
correct sizes, known dimensions, and lazy behavior that respects the user.
